平板型光伏太阳能热泵热水系统性能模拟分析

葛晓慧; 徐亮; 张雪松; 赵波; 董科枫; 李舒宏

doi:10.16513/j.cnki.10-1427/tk.2016.03.005

PDF(1627 KB)

分布式能源 ›› 2016, Vol. 1 ›› Issue (3) : 29-36. DOI: 10.16513/j.cnki.10-1427/tk.2016.03.005

平板型光伏太阳能热泵热水系统性能模拟分析

葛晓慧 ¹ ,
徐亮 ² ,
张雪松 ¹ ,
赵波 ¹ ,
董科枫 ² ,
李舒宏 ²

作者信息 +

Performance Simulation of Photovoltaic Solar Assisted-Heat Pump Water Heating System

Author information +

文章历史 +

摘要

为了研究光伏太阳能热泵热水系统的相关性能，针对该系统的结构特点，运用集总参数法分别建立了光伏/蒸发器、压缩机、冷凝器、电子膨胀阀的稳态数学模型。通过所建的模型分析了光伏太阳能热泵热水系统在不同的环境温度、太阳辐射强度、风速以及压缩机转速下的光电、光热输出特性的变化规律；并以南京地区为例，将光伏太阳能热泵热水系统与传统直膨式太阳能热泵热水系统、无冷却的太阳能光伏系统对比。结果显示，光伏太阳能热泵系统较太阳能光伏系统的全年发电量提高了31.5%；光伏太阳能热泵系统的全年平均热电综合性能系数可达到8.83，远高于传统太阳能热泵系统的性能系数。

Abstract

The lumped parameter method was introduced to build the steady state models of photovoltaic solar assisted-heat pump water heater (PV-SAHP) system, so as to study the performance of photovoltaic solar heat pump hot water system. The models, covering PV evaporator, compressor，condenser, electronic expansion valve, were used to analyze the changes of electrical efficiency and thermal efficiency with varying environmental temperature, solar radiation, wind speed and compressor capacity. Based on the meteorological data in Nanjing, the performance of proposed PV-SAHP system was compared with that of traditional direct expansion solar assisted-heat pump water heating (DX-SAHP) system and PV system. The results show that the annual power generation of PV-SAHP system is more than that of DX-SAHP system by 31.5%; the average coefficient of performance of PV/T-SAHP system can reach 8.83, considerably higher than that of SAHP system.

导出引用

葛晓慧, 徐亮, 张雪松, 等. 平板型光伏太阳能热泵热水系统性能模拟分析[J]. 分布式能源. 2016, 1(3): 29-36 https://doi.org/10.16513/j.cnki.10-1427/tk.2016.03.005

Xiaohui GE, Liang XU, Xuesong ZHANG, et al. Performance Simulation of Photovoltaic Solar Assisted-Heat Pump Water Heating System[J]. Distributed Energy Resources. 2016, 1(3): 29-36 https://doi.org/10.16513/j.cnki.10-1427/tk.2016.03.005

中图分类号：

参考文献

列表( 原文顺序 | 文献年度倒序 | 文中引用次数倒序 ) 可视化分析

[1]	TRIPANAGNOSTOPOULOS Y, NOUSIA T, SOULIOTIS M, et al. Hybrid photovoltaic/thermal solar systems[J]. Solar Energy, 2002, 72(3): 217-234. 本文引用 [1]

[2]	龙文志. 光电光热建筑一体化(BIPVT)概论[J]. 中国建筑金属结构，2012(9): 35-43. LONG Wenzhi. Introduction to photoelectric thermal building integration (BIPVT)[J]. China Construction Metal Structure, 2012(9): 35-43. 本文引用 [1]

[3]	董丹，秦红，刘重裕，等. 太阳能光伏/热(PV/T)技术的研究进展[J]. 化工进展，2013, 32(5): 1020-1024. DONG Dan, QIN Hong, LIU Chongyu, et al. Reseach progress in solar photovoltaic/thermal technology[J]. Chemical Industry and Engineering Progress, 2013, 32(5): 1020-1024. 本文引用 [1]

[4]	王宝群，姚强，宋蔷，等. 光伏/光热(PVT)系统概况与评价[J]. 太阳能学报，2009, 30(2): 193-200. WANG Baoqun, YAO Qiang, SONG Qiang, et al. Overview and evaluation of photovoltaic/thermal (PVT) system[J]. Acta Energiae Solaris Sinica, 2009, 30(2): 193-200. 本文引用 [1]

[5]	ITO S, MIURA N, WANG J Q, et al. Heat pump using a solar collector with photovoltaic modules on the surface[J]. Journal of Solar Energy Engineering, 1997, 119(2): 147-151. 本文引用 [1]

[6]	ITO S, MIURA N, TAKANO Y. Studies of heat pumps using direct expansion type solar collectors[J]. Journal of solar energy engineering, 2005, 127(1): 60-64. 本文引用 [2]

[7]	JI J, PEI G, CHOW T, et al. Experimental study of photovoltaic solar assisted heat pump system[J]. Solar Energy, 2008, 82(1): 43-52. 本文引用 [1]

[8]	JI J, HE H, CHOW T, et al. Distributed dynamic modeling and experimental study of PV evaporator in a PV/T solar-assisted heat pump[J]. International Journal of Heat and Mass Transfer, 2009, 52(5): 1365-1373. 本文引用 [1]

[9]	裴刚，李晶，季杰. 玻璃盖板对光伏-太阳能热泵冬季综合性能的影响[J]. 太阳能学报，2010, 31(3): 323-327. PEI Gang, LI Jing, JI Jie. Energy and exergy analysis of photovoltaic solar assisted heat pump system in winter[J]. Acta Energiae Solaris Sinica, 2010, 31(3): 323-327. 本文引用 [1]

[10]	CHOW T T, FONG K F, PEI G, et al. Potential use of photovoltaic integrated solar heat pump system in Hong Kong[J]. Applied Thermal Engineering, 2010, 30(8-9): 1066-1072. 本文引用 [1]

[11]	徐国英，张小松，杨磊. 两种集热结构的太阳能光伏/光热一体化热泵性能分析[J]. 化工学报，2008, 59(2): 224-229. XU Guoying, ZHANG Xiaosong, YANG Lei. Performance evaluation of PV/T integrated heat pump using two different collector/evaporators[J]. CIESC Journal, 2008, 59(2): 224-229. 本文引用 [1]

[12]	KIM S G, KIM Y J, LEE G, et al. The performance of a transcritical CO₂, cycle with an internal heat exchanger for hot water heating[J]. International Journal of Refrigeration, 2005, 28(7): 1064-1072. 本文引用 [1]

[13]	丁国良，黄冬平. 二氧化碳制冷技术[M]. 北京：化学工业出版社，2006: 253-264. 本文引用 [1]

[14]	Shah M M. A general correlation for heat transfer during film condensation inside pipes[J]. International Journal of Heat & Mass Transfer, 1979, 22(4): 547-556. 本文引用 [1]

[15]	HUANG B J, LIN T H, HUNG W C, et al. Performance evaluation of solar photovoltaic/thermal systems[J]. Solar Energy, 2001, 70(5): 443-448. 本文引用 [1]
