300 MW循环流化床机组供热节能方案对比分析

吕剑; 吴喜生; 肖瑶; 徐钢; 王鹏

doi:10.16513/j.cnki.10-1427/tk.2016.03.009

PDF(1324 KB)

分布式能源 ›› 2016, Vol. 1 ›› Issue (3) : 55-62. DOI: 10.16513/j.cnki.10-1427/tk.2016.03.009

300 MW循环流化床机组供热节能方案对比分析

吕剑 ¹^,² ,
吴喜生 ¹ ,
肖瑶 ² ,
徐钢 ² ,
王鹏 ³

作者信息 +

Comparison Analysis of Energy-Saving Heat Supply Scheme for 300 MW Circulating Fluidized Bed Power Units

Jian LYU ¹^,² ,
Xisheng WU ¹ ,
Yao XIAO ² ,
Peng XU ³ ,
Gang WANG ²

Author information +

文章历史 +

摘要

为了应对近年来北方供热需求的不断增加，提出对现有300 MW亚临界直接空冷机组进行供热改造。基于高背压乏汽供热和吸收式热泵这2种火力发电厂余热利用技术，通过对原有抽凝供热机组采用这2种余热利用方案进行热经济性计算与分析，确定了适合该电厂空冷机组的余热利用改造方案。结果表明，高背压供热和吸收式热泵这2供热改造方案节能效果显著，总煤耗量降低；且对比同一发电负荷下，高背压供热节标煤量比吸收式热泵供热的节标煤量多，最大供热面积和最大供热负荷更大。如在最大供热负荷下，高背压供热和吸收式热泵供热分别将供电煤耗降至168.9、197.2 g/(kW·h)；而在同一发电负荷下，高背压供热最大供热负荷比热泵供热多73.6 MW，最大供热面积多133.8×10⁴ m³。

Abstract

The heat supply retrofitting is carried out on existing 300 MW sub-critical direct air cooling units to meet the increasing heating demand in northern China. Two waste heat utilization technologies for power plants were introduced, namely high back pressure heat supply and absorption heat pump heat supply. Based on the economic analysis of two waste heat utilization schemes, the proper solution was determined for the direct air-cooling power unit. The results show that high back pressure heat supply and absorption heat pump heat supply both have remarkable energy-saving effect, decreasing the total coal consumption. For given load, the coal rate of high back pressure heat supply is even lower than that of absorption heat pump heating with the maximum heating area and heating load. Specifically, under the maximum heating load, the coal rate is reduced to 168.9 g/(kW·h) and 197.2 g/(kW·h) through high back pressure and absorption heat pump heat supply. Under the same power load, the maximum heating load and heating area of high back pressure heat supply are 73.6 MW and 133.8×10⁴ m² higher than those of absorption heat pump heating.

导出引用

吕剑, 吴喜生, 肖瑶, 等. 300 MW循环流化床机组供热节能方案对比分析[J]. 分布式能源. 2016, 1(3): 55-62 https://doi.org/10.16513/j.cnki.10-1427/tk.2016.03.009

Jian LYU, Xisheng WU, Yao XIAO, et al. Comparison Analysis of Energy-Saving Heat Supply Scheme for 300 MW Circulating Fluidized Bed Power Units[J]. Distributed Energy Resources. 2016, 1(3): 55-62 https://doi.org/10.16513/j.cnki.10-1427/tk.2016.03.009

中图分类号：

参考文献

列表( 原文顺序 | 文献年度倒序 | 文中引用次数倒序 ) 可视化分析

[1]	李岩，付林，张世钢，等. 电厂循环水余热利用技术综述[J]. 建筑科学，2010, 26(10): 10-14. 本文引用 [1]

[2]	苏永. 300 MW直接空冷机组乏汽余热利用改造方案研究[J]. 环境保护与循环经济，2016, 36(1): 42-46. 本文引用 [2]

[3]	赵云凯，刘汉涛，张培华，等. 高背压供热与吸收式热泵供热能耗分析对比[J]. 煤炭技术，2015, 34(2): 321-323. ZHAO Yunkai, LIU Hantao, ZHANG Peihua, et al. Energy consumption analysis and contrast on high back pressure and absorption heat pump heating[J]. Coal Technology, 2015, 34(2): 321-323. 本文引用 [1]

[4]	常立宏. 300 MW亚临界供热机组高背压供热改造的研究[J]. 黑龙江电力，2012, 34(6): 421-423. CHANG Lihong. Study of 300 MW subcritical heating unit high backpressure heating transformation[J]. Heilongjiang Electric Power, 2012, 34(6): 421-423. 本文引用 [1]

[5]	史敬杰，张晓静. 高背压供热技术在300 MW空冷供热机组的应用[J]. 科技展望，2015, 25(28): 62. 本文引用 [2]

[6]	汪滔. 吸收式热泵用于大连华能电厂的供暖改造研究[D]. 哈尔滨：哈尔滨工业大学，2010. WANG Tao. Study on heating restruction of absorption heat pump in Dalian Power Plant of China Huneng Group[D]. Harbin: Harbin Institute of Technology, 2010. 本文引用 [1]

[7]	陈玉勇. 基于吸收式热泵的热电联产系统节能研究[D]. 北京：华北电力大学，2014. CHEN Yuyong. Energy saving research of cogeneration based on the absorption heat pump system[D]. Beijing: North China Electric Power University, 2014. 本文引用 [1]

[8]	李浩，李泽敏. 吸收式热泵循环水余热回收方案在300 MW机组的应用[J]. 科技视界，2012(24): 298-299. 本文引用 [1]

[9]	常立宏. 300 MW亚临界供热机组高背压供热改造研究[C]//大机组供热改造与优化运行技术2013年会. 苏州：中国电机工程学会，2013. CHANG Lihong. Study of 300 MW subcritical heating unit high backpressure heating transformation[C]//Large Unit Heating Transformation and Optimization of the Operation. Suzhou: CSEE, 2013. 本文引用 [1]

[10]	张攀，杨涛，杜旭，等. 直接空冷机组高背压供热技术经济性分析[J]. 汽轮机技术，2014, 56(3): 209-212. ZAHNG Pan, YANG Tao, DU Xu, et al. The economy analysis of the high back pressure heating technology on direct air-colled unit[J]. Steam Turbine Technology, 2014, 56(3): 209-212. 本文引用 [1]
