改进下垂控制在三相三电平PWM整流器中的应用

王聪聪; 肖伸平

doi:10.16513/j.cnki.10-1427/tk.2017.05.004

PDF(1226 KB)

分布式能源 ›› 2017, Vol. 2 ›› Issue (5) : 24-29. DOI: 10.16513/j.cnki.10-1427/tk.2017.05.004

学术研究

改进下垂控制在三相三电平PWM整流器中的应用

王聪聪 ,
肖伸平

作者信息 +

Application of Improved Droop Control in Three-Phase Three-Level PWM Rectifier

Author information +

文章历史 +

摘要

针对三相三电平脉宽调制（pulse-width modulation，PWM）整流器的中点平衡问题，提出一种改进的下垂控制策略。首先，基于空间矢量控制，分析三相三电平PWM整流器的主电路拓扑结构，并建立数学模型；其次，对反馈电压电流进行dq解耦，并引入一个下垂系数对反馈电压进行修正，从而提高输出电压的跟踪性能，并实现快速单位功率因数控制及快速瞬间响应。最后，通过Matlab/Simulink仿真分析，验证了该控制策略具有较好的动态性能及静态性能。

Abstract

According to the neutral-point balance problem of three-phase three-level pulse-width modulation （PWM） rectifier, this paper proposes a improved droop control. Firstly, based on the space vector control, we analyze the main circuit topology of the three-phase three-level PWM rectifier and establish its mathematical model. Then, we realize the dq decoupling of feedback voltage and current, and introduce a droop coefficient to correct the feedback voltage；so then, the tracking performance of the output voltage is improved, and fast unit power factor control and fast transient response are achieved. Finally, through Matlab/Simulink simulation, it is proved that the control strategy has good dynamic performance and static performance.

导出引用

王聪聪, 肖伸平. 改进下垂控制在三相三电平PWM整流器中的应用[J]. 分布式能源. 2017, 2(5): 24-29 https://doi.org/10.16513/j.cnki.10-1427/tk.2017.05.004

Congcong WANG, Shenping XIAO. Application of Improved Droop Control in Three-Phase Three-Level PWM Rectifier[J]. Distributed Energy Resources. 2017, 2(5): 24-29 https://doi.org/10.16513/j.cnki.10-1427/tk.2017.05.004

参考文献

列表( 原文顺序 | 文献年度倒序 | 文中引用次数倒序 ) 可视化分析

[1]	LOH P C, LI D, CHAI Y K，et al. Autonomous operation of hybrid microgrid with AC and DC subgrids[J]. IEEE Transactions on Power Electronics，2013，28(5):2214-2223. 本文引用 [1]

[2]	WANG P, GOEL L, LIU X，et al. Harmonizing AC and DC：a hybrid AC/DC future grid solution[J]. IEEE Power & Energy Magazine，2013，11(3):76-83. 本文引用 [1]

[3]	POU J, PINDADO R, BOROYEVICH D，et al. Evaluation of the low-frequency neutral-point voltage oscillations in the three-level inverter[J]. IEEE Transactions on Industrial Electronics，2005，52(6):1582-1588. 本文引用 [1]

[4]	GUPTA A K, KHAMBADKONE A M. A simple space vector PWM scheme to operate a three-level NPC inverter at high modulation index including overmodulation region，with neutral point balancing[J]. IEEE Transactions on Industry Applications，2007，43(3):751-760. 本文引用 [1]

[5]	姚绪梁，王旭，冯泽文. 改善三相电压型PWM整流器动态性能的研究[J]. 电工技术学报，2016，31(S1):169-175. YAO Xuliang, WANG Xu, FENG Zewen. Research on improvement of the dynamic ability for PWM rectifier[J]. Transactions of China Electrotechnical Society，2016，31(S1):169-175. 本文引用 [1]

[6]	刘博，贲洪奇，白银龙，等. PWM整流器轻载条件下网侧电流谐波分析与抑制[J].电工技术学报，2016，31(S1):162-168. LIU Bo, BEN Hongqi, BAI Yinlong，et al. Analysis and suppression of current harmonics in grid side of PWM rectifiers during light load[J]. Transactions of China Electrotechnical Society，2016，31(S1):162-168. 本文引用 [1]

[7]	NUSSBAUMER T, BAUMANN M, KOLAR J W. Comprehensive design of a three-phase three-switch buck-type PWM rectifier[J]. IEEE Transactions on Power Electronics，2007，22(2):551-562. 本文引用 [1]

[8]	顾玲，金科，周慧龙. 单级式隔离型三相双向AC/DC变换器及其SVPWM调制策略[J]. 中国电机工程学报，2015，35(15):3886-3894. GU Ling, JIN Ke, ZHOU Huilong. A single-stage three-phase isolated bidirectional AC/DC converter and its SVPWM algorithm[J]. Proceedings of the CSEE，2015，35(15):3886-3894. 本文引用 [2]

[9]	倪双舞，苏建徽. 以电容储能作为外环反馈变量的双闭环多电平整流器控制策略[J]. 电工技术学报，2016，31(9):92-100. NI Shuangwu, SU Jianhui. A dual closed loop control strategy of the multi-level rectifier using capacitor energy as the outer loop variable[J]. Transactions of China Electrotechnical Society，2016，31(9):92-100. 本文引用 [2]

[10]	宋治楷，胥飞，王恒. 基于下垂控制的三电平逆变器并联技术仿真研究[J]. 可再生能源，2016，34(11):1651-1657. SONG Zhikai, XU Fei, WANG Heng. Simulation research on parallel technology of three level inverter based on droop control[J]. Renewable Energy Resources，2016，34(11):1651-1657. 本文引用 [1]

[11]	吕义. 基于下垂控制的并联逆变器建模与分析[J]. 电气工程学报，2016，11(5):21-29. LÜ Yi. Modeling and analysis of parallel inverters based on droop control[J]. Journal of Electrical Engineering，2016，11(5):21-29. 本文引用 [1]

[12]	张明锐，杜志超，王少波. 微网中下垂控制策略及参数选择研究[J]. 电工技术学报，2014，29(2):136-144. ZHANG Mingrui, DU Zhichao, WANG Shaobo. Research on droop control strategy and parameters selection of microgrids[J]. Transactions of China Electrotechnical Society，2014，29(2):136-144. 本文引用 [1]

[13]	刘佳易，秦文萍，韩肖清，等. 交直流双向功率变换器的改进下垂控制策略[J]. 电网技术，2014，38(2):304-310. LIU Jiayi, QIN Wenping, HAN Xiaoqing，et al. Control method of interlink-converter in DC microgrid[J]. Power System Technology，2014，38(2):304-310. 本文引用 [1]

[14]	MAJUMDER R, CHAUDHURI B, GHOSH A，et al. Improvement of stability and load sharing in an autonomous microgrid using supplementary droop control loop[J]. IEEE Transactions on Power Systems，2010，25(2):796-808. 本文引用 [1]

[15]	NUSSBAUMER T, KOLAR J W. Improving mains current quality for three-phase three-switch buck-type PWM rectifiers[J]. IEEE Transactions on Power Electronics，2017，21(4):967-973. 本文引用 [1]
