含大规模风光电源的电网静态电压稳定性分析

赵会莹; 杨明玉

doi:10.16513/j.cnki.10-1427/tk.2017.05.007

PDF(827 KB)

分布式能源 ›› 2017, Vol. 2 ›› Issue (5) : 41-46. DOI: 10.16513/j.cnki.10-1427/tk.2017.05.007

学术研究

含大规模风光电源的电网静态电压稳定性分析

赵会莹 ,
杨明玉

作者信息 +

Static Voltage Stability Analysis on Grid With Large Scale Wind and Photovoltaic Power

Author information +

文章历史 +

摘要

针对电压稳定评估指标从有功功率或无功功率单方面去评价而产生的结果差异问题，提出了一种用于分析大规模风电场、光伏电站接入电网后系统静态电压稳定性的综合评价指标。通过功率-电压曲线计算节点电压的有功灵敏度指标I_P，来研究风电场、光伏电站联合接入电网后的风光电源有功出力变化对系统电压稳定性的影响；通过计算含大规模风光电源的系统节点电压-无功灵敏度指标I_Q，来进行系统电压稳定性的评估；在这基础上，根据理想点法将这2种指标进行综合得到系统的综合评价指标I.利用评价指标I_P、I_Q、I对山西省实际电网的静态电压稳定性进行分析，判断出山西电网中电压相对薄弱节点和区域，并对这3个指标下的电网电压薄弱区域进行对比分析，验证了综合评价指标的全面性。

Abstract

The voltage stability index was merely established from the perspective of active power or reactive power, and it might generate different results. In order to solve the problem, this paper proposes an integrated voltage stability index to analyze the static voltage stability of the grid with large scale wind farm and photovoltaic plant connection. On one hand, it obtains the active sensitivity index IP of node voltage through power-voltage curve to study the impact of the active power change of wind-photovoltaic generation of the grid with wind farm and photovoltaic plant connection on the voltage stability of system. On the other hand, the node voltage reactive sensitivity index IQ of the grid with wind farm and photovoltaic plant connection is used in evaluating voltage stability of power system. On this basis, the integrated voltage stability index I is proposed by the integration of the above two indices based on ideal point method. We use the evaluation indexes IP, IQ and I to analyze the static voltage stability of the actual power grid in Shanxi province, which can identify the weak buses and areas of Shanxi grid. The comparison and analysis of the weak area of power grid under these three indexes verifies the comprehensiveness of the comprehensive evaluation index.

导出引用

赵会莹, 杨明玉. 含大规模风光电源的电网静态电压稳定性分析[J]. 分布式能源. 2017, 2(5): 41-46 https://doi.org/10.16513/j.cnki.10-1427/tk.2017.05.007

Huiying ZHAO, Mingyu YANG. Static Voltage Stability Analysis on Grid With Large Scale Wind and Photovoltaic Power[J]. Distributed Energy Resources. 2017, 2(5): 41-46 https://doi.org/10.16513/j.cnki.10-1427/tk.2017.05.007

参考文献

列表( 原文顺序 | 文献年度倒序 | 文中引用次数倒序 ) 可视化分析

[1]	汪宁渤，马彦宏，王建东. 大规模风电集中并网对电力系统安全稳定的影响[J]. 电力建设，2011，32(11):77-80. WANG Ningbo, MA Yanhong, WANG Jiandong. Analysis of power system security and stability caused by large-scale wind power grid integration[J]. Electric Power Construction，2011，32(11):77-80. 本文引用 [1]

[2]	丁明，王伟胜，王秀丽，等. 大规模光伏发电对电力系统影响综述[J]. 中国电机工程学报，2014，34(1):1-14. DING Ming, WANG Weisheng, WANG Xiuli，et al.A review on the effect of large-scale PV generation on power systems[J]. Proceedings of the CSEE，2014，34(1):1-14. 本文引用 [1]

[3]	BEGOVIC M M, PHADKE A G. Control of voltage stability using sensitivity analysis[J]. IEEE Transaction on Power Systems，1992，7(1):114-123. 本文引用 [1]

[4]	李兴源，王秀英. 基于静态等值和奇异值分解的快速电压稳定性分析方法[J]. 中国电机工程学报，2003，23(4):1-4,20. LI Xingyuan, WANG Xiuying. Fast voltage stability analysis methods based on static equivalence and singular value resolution[J]. Proceedings of the CSEE，2003，23(4):1-4,20. 本文引用 [1]

[5]	NAM H K, KIM Y K, SHIM K S，et al. A new eigen-sensitivity theory of augmented matrix and its applications to power system stability analysis[J]. IEEE Transactions onPower Systems，2000，15(1):363-369. 本文引用 [1]

[6]	傅旭，付翀丽，黄明良. 一种提高电力系统静态电压稳定裕度的切负荷算法[J]. 电力建设，2014，35(9):71-75. FU Xu, FU Zhongli, HUANG Mingliang. A New Load shedding algorithm to improve static voltage stability margin for power system[J]. Electric Power Construction，2014，35(9):71-75. 本文引用 [1]

[7]	姜惠兰，秦景忠，郑双琦，等. 含风机电网静态电压稳定薄弱区域分析[J]. 电力系统及其自动化学报，2015，27(12):7-11. JIANG Huilan, QIN Jingzhong, ZHENG Shuangqi，et al. Study on weak area of static voltage stability for grid containing wind farms[J]. Proceedings of the CSU-EPSA，2015，27(12):7-11. 本文引用 [1]

[8]	OBADINA O O, BERG G J. Identifying electrically weak and strong segments of a power system from a voltage stability viewpoint[J]. IEE Proceedings of Generation，Transmission and Distribution，1990，137(3):205-212. 本文引用 [1]

[9]	陈敏，张步涵，段献忠，等.基于最小奇异值灵敏度的电压稳定薄弱节点研究[J]. 电网技术，2006，30(24):36-40. CHEN Min, ZHANG Buhan, DUAN Xianzhong，et al.Study on weak buses of voltage stability based on sensitivity of minimum singular value[J]. Power System Technology，2006，30(24):36-40. 本文引用 [1]

[10]	GAO B, MORISON G K, KUNDUR P. Voltage stability evaluation using modal analysis[J]. IEEE Transaction on Power Systems，1992，7(4):1529-1542. 本文引用 [1]

[11]	韩光，丁晓群，刘小波，等. 基于模态技术和Q-U 曲线的一种电压稳定性指标[J]. 继电器，2006，34(6):21-23. HAN Guang, DING Xiaoqun, LIU Xiaobo，et al. An index of voltage stability based on modal analysis and Q-U curve[J]. Relay，2006，34(6):21-23. 本文引用 [1]

[12]	高鹏，石立宝，姚良忠，等. 辨识电网薄弱节点的多准则综合电压稳定指标[J]. 电网技术，2009，33(19):26-31. GAO Peng, SHI Libao, YAO Liangzhong，et al. A multi-criterion integrated voltage stability index for weak buses identification[J]. Power System Technology，2009，33(19):26-31. 本文引用 [1]

[13]	卢锦玲，石少通，卢洋. 含大规模风电场的电网静态电压稳定性评估[J]. 电力系统及其自动化学报，2015，27(6):73-80. LU Jinling, SHI Shaotong, LU Yang. Static voltage stability assessment on the grid with large-scale wind farm connection[J]. Proceedings of the CSU-EPSA，2015，27(6):73-80(in Chinese). 本文引用 [2]

[14]	王颖，赵俊楷，侯杰群. 基于一种综合指标的河北南网静态电压稳定分析[J]. 智能电网，2016(11):1093-1098. WANG Ying, ZHAO Junkai, HOU Jiequn. Analysis of static voltage stability for Hebei southern power grid based on a new integrated index[J]. Smart Grid，2016(11):1093-1098. 本文引用 [1]

[15]	中华人民共和国国家经济贸易委员会.DL 755—2001 电力系统安全稳定导则[S]. 北京：中国电力出版社，2011. 本文引用 [1]

[16]	IEEE/CIGRE Joint Task Force on Stability Terms and Definitions. Definition and classification of power system stability[J]. IEEE Transactions on Power Systems，2004，19(2):1387-1401. 本文引用 [1]
