基于大数据的风电生产运营监控系统设计与实现

尹诗; 迟岩; 王其乐; 王寅生; 何伟

doi:10.16513/j.cnki.10-1427/tk.2017.05.010

PDF(1219 KB)

分布式能源 ›› 2017, Vol. 2 ›› Issue (5) : 60-64. DOI: 10.16513/j.cnki.10-1427/tk.2017.05.010

应用技术

基于大数据的风电生产运营监控系统设计与实现

作者信息 +

Wind Power Operation Management and Control Center Based on Big Data

Author information +

文章历史 +

摘要

随着风力发电机组装机规模不断扩大，风电企业对生产运营及设备管控提出了更高的要求。为更客观地评价风电企业运营管控状况，各大运行商相继建立了风电生产运营监控中心，以实现对下辖风电企业进行精细化管理。传统风电生产运营监控系统以实时数据库作为底层数据存储，以单台硬件作为系统后台计算资源；但是，伴随着计算指标，尤其数据存储的增加，传统的数据存储架构已满足不了当前系统建设的需要。提出基于大数据的风电生产运营监控系统设计架构，并在此基础上实现风电生产运营监控、经营管控指标计算等功能。国内某大型风电运营商已应用该系统，实现了每年600 TB的秒级风机数据存储，形成了适合风电企业发展需要并具有扩展能力的数据中心。

Abstract

With the larger scale of installed wind power operators, wind power enterprises of production operation and equipment control get higher requirements. To better control the objective evaluation of the wind power enterprises operation, each enterprise has set up wind power production operation monitoring center to administer wind power enterprises to carry out fine management. Traditionally, wind power production operation monitoring system takes real time database as the underlying data store, and a single hardware as the system background computing resource. However, with the calculation index, especially the increase of data storage, the traditional data storage architecture has already can't satisfy the need of the construction of the current system. This paper proposes the wind power production operation monitoring system design framework based on big data, and on this basis to realize the wind power production operation monitoring, wind power management control indicators, and other functions. The system has been applied in a large wind power operator in China, realized the data storage of fan per second of 600 TB per year, and formed a data center which is suitable for the development of wind power enterprises and has the ability to expand.

导出引用

尹诗, 迟岩, 王其乐, 等. 基于大数据的风电生产运营监控系统设计与实现[J]. 分布式能源. 2017, 2(5): 60-64 https://doi.org/10.16513/j.cnki.10-1427/tk.2017.05.010

Shi YIN, Yan CHI, Qile WANG, et al. Wind Power Operation Management and Control Center Based on Big Data[J]. Distributed Energy Resources. 2017, 2(5): 60-64 https://doi.org/10.16513/j.cnki.10-1427/tk.2017.05.010

参考文献

列表( 原文顺序 | 文献年度倒序 | 文中引用次数倒序 ) 可视化分析

[1]	国家电投集团内蒙古能源集团有限责任公司. 集团级电力生产指标实时监控、对标及分析一体化管控平台的研发与应用[R]. 呼和浩特：国家电投集团内蒙古能源集团有限责任公司，2013. 本文引用 [1]

[2]	汪喆. 基于大数据分析的风电机组运行状态监测评估[D]. 北京：华北电力大学，2016. WANG Zhe. Based on large data analysis of wind turbine operation monitoring and evaluation[D]. Beijing：North China Electric Power University，2016. 本文引用 [1]

[3]	GUO Peng, INFIELD D, YANG Xiyun. Wind turbine generator condition monitoring using temperature trend analysis[J]. IEEE Transactions on Sustainable Energies，2012，3(1):124-133. 本文引用 [1]

[4]	中国电机工程学会. 中国电力大数据发展白皮书[R]. 北京：中国电机工程学会，2013. 本文引用 [1]

[5]	孙大为，张广艳，郑纬民. 大数据流式计算：关键技术及系统实例[J]. 软件学报，2014，25(4):839-862. SUN Dawei, ZHANG Guangyan, ZHENG Weimin. Big data flow calculation：key technology and system instance[J]. Journal of Software，2014，25(4):839-862. 本文引用 [1]

[6]	SAAVEDRA-MORENO B, SALCEDO-SANZ S, PANIAGUA-TINEO A，et al. Seeding evolutionary algorithms with heuristics for optimal wind turbines positioning in wind farms[J]. Renewable Energy，2011，36(11):2838-2844. 本文引用 [1]

[7]	XU D P, ZHANG X F, LIU Y B. Overview of relevant control problems of wind turbines[J]. Electric Power，2005，38(4):70-74. 本文引用 [1]

[8]	XIAO Yunqi, JIA Pengxiao. A novel optimum power fuzzy control strategy for doubly-fed wind turbine[C]//Proceedings of 8th ICCA，Xiamen，2010. 本文引用 [1]

[9]	XIAO Yunqi, LÜ Yuegang. Pitch-controlled wind turbine synchronized cutting-in control and modeling-simulation[C]//Proceedings of WCICA，Bejing，2012. 本文引用 [1]

[10]	WANG Wei, LIU Jizhen, ZENG Deliang，et al. An improved coordinated control strategy for boiler-turbine units supplemented by cold source flow adjustment[J]. Energy，2015，88:927-934. 本文引用 [1]

[11]	TAN Wen, MARQUEZ H J, CHEN Tongwen，et al. Analysis and control of a nonlinear boiler-turbine unit[J]. Journal of Process Control，2005，15(8):883-891. 本文引用 [1]

[12]	YANG Xiyun, GUO Peng. Petri net model and reliability evaluation for wind turbine hydraulic variable pitch system[J]. Energies，2011，4(6):978-997. 本文引用 [1]

[13]	LIU Xiangjie, JIANG D, LEE K Y. Quasi-min-max fuzzy MPC of UTSG water level based on off-line invariant set[J]. IEEE Trans. on Nuclear Science，2015，62(5):2266-2272. 本文引用 [1]

[14]	LIU Xiangjie, KONG Xiaobing. Nonlinear model predictive control for DFIG-based wind power generation[J]. IEEE Transactions on Automation Science and Engineering：Regular Paper，2014，11(4):1046-1055. 本文引用 [1]
