微电网多端口变换器拓扑结构研究综述

曾进辉; 何智成; 孙志峰; 张伯伦; ZENG Jinhui; HE Zhicheng; SUN Zhifeng; ZHANG Bolun

doi:10.16513/j.cnki.10-1427/tk.2017.06.001

PDF(1109 KB)

分布式能源 ›› 2017, Vol. 2 ›› Issue (6) : 1-7. DOI: 10.16513/j.cnki.10-1427/tk.2017.06.001

微电网多端口变换器拓扑结构研究综述

作者信息 +

Research Review on Multiport Converter Topology in Micro Power Grid

Author information +

文章历史 +

摘要

The development of micro grid has become an objective need to crack high permeability distributed energy efficient and secure access to power grid, as the key device of power conversion in micro grid, multi-port converter (MPC) has great application value and broad application pro-spects in the construction of micro grid. This paper first analyzes the development process of power converter topology, on this basis, analyzes and compares the typical topologies of two port converter, three port converter, four port converter and multi port converter for micro grid. Then, it is pointed out that the MPC in power density, conversion efficiency, converter function, etc., has advantages over conventional dual-port converter, which is the future direction of the energy converter. Finally, several key technical problems of MPC to be solved in the engineering application are pointed out from aspects of the topology, power flow control and operation reliability, and the development trend of MPC in micro grid is analyzed from several aspects.

关键词

微电网 / 多端口变换器(MPC) / 功率密度 / 拓扑结构 / 电能路由器 / 电能转换 / 转换效率 / micro power grid / multi-port converters (MPC) / power density / topology / power router / electrical energy conversion / conversion efficiency

引用本文

EndNote

Ris (Procite)

Bibtex

导出引用

曾进辉, 何智成, 孙志峰, 等. Research Review on Multiport Converter Topology in Micro Power Grid[J]. 分布式能源. 2017, 2(6): 1-7 https://doi.org/10.16513/j.cnki.10-1427/tk.2017.06.001

[J]. Distributed Energy Resources. 2017, 2(6): 1-7 https://doi.org/10.16513/j.cnki.10-1427/tk.2017.06.001
