压缩空气储能膨胀机进气阀严密性试验

文贤馗; 张世海; 盛勇; 白阳; WEN Xiankui; ZHAGN Shihai; SHENG Yong; BAI Yang

doi:10.16513/j.cnki.10-1427/tk.2017.06.005

PDF(754 KB)

分布式能源 ›› 2017, Vol. 2 ›› Issue (6) : 26-30. DOI: 10.16513/j.cnki.10-1427/tk.2017.06.005

压缩空气储能膨胀机进气阀严密性试验

文贤馗 ¹ ,
张世海 ¹ ,
盛勇 ² ,
白阳 ² ,
WEN Xiankui ¹ ,
ZHAGN Shihai ¹ ,
SHENG Yong ² ,
BAI Yang ²

作者信息 +

Inlet Valve Leak Test for Turbine Expander of CAES

Author information +

文章历史 +

摘要

At present, the scheme adopted in inlet valve leak test of the expander in compressed air energy storage (CAES) power station and the test parameter are not definite, the leak test lacks the scientific demonstration, and there is no quantitative index of whether the inlet valve is tight. In order to estimate the leakage of inlet valve accurately and ensure the safe running of CAES power plant, through comparative analysis on the inlet valve tightness test method of steam turbine and gas turbine in thermal power and nuclear power, in combination with the structural dynamic characteristics of expander and its operation features, this paper puts forward the inlet valve leak test method of expander and its judgment basis, and compares the idling time data of different time periods to obtain the variation of CAES inlet valve leak test. The method introduces the expander speed as the judgment basis and quantifies the acceptable index of leak test, which makes the test more objective and operable, and ensures the safe and stable operation of expander.

关键词

压缩空气储能 / 透平膨胀机 / 进气阀严密性 / 汽轮机 / 燃气轮机 / compressed air energy storage / turbine expander / inlet valve leak test / steam turbine / gas turbine

引用本文

EndNote

Ris (Procite)

Bibtex

导出引用

文贤馗, 张世海, 盛勇, 等. Inlet Valve Leak Test for Turbine Expander of CAES[J]. 分布式能源. 2017, 2(6): 26-30 https://doi.org/10.16513/j.cnki.10-1427/tk.2017.06.005

[J]. Distributed Energy Resources. 2017, 2(6): 26-30 https://doi.org/10.16513/j.cnki.10-1427/tk.2017.06.005

参考文献

列表( 原文顺序 | 文献年度倒序 | 文中引用次数倒序 ) 可视化分析

[1]	张新敬，陈海生，刘金超，等. 压缩空气储能技术研究进展[J]. 储能科学与技术，2012, 1(1): 26-40. ZHANG Xinjing, CHEN Haisheng, LIU Jinchao, et al. Research progress in compressed air energy storage system: A review[J]. Energy Storage Science and Technology, 2012, 1(1): 26-40. 本文引用 [1]

[2]	韩中合，庞永超. 先进绝热压缩空气储能中蓄热系统的改进[J]. 分布式能源，2016, 1(1): 22-27. HAN Zhonghe, PANG Yongchao. Modification of thermal energy storage system in AA-CAES[J]. Distributed Energy, 2016, 1(1): 22-27. 本文引用 [1]

[3]	张新敬. 压缩空气储能系统若干问题的研究[D]. 北京：中国科学院研究生院，2011. ZHANG Xinjing. Investigation on compressed air energy storage system[D]. Beijing: Graduate University of the Chinese Academy of Sciences, 2011. 本文引用 [1]

[4]	Benjamin Bollinger. Technology performance report sustainx smart grid program[R]. Department of Energy's National Energy Technology Laboratory, 2015. 本文引用 [1]

[5]	郭欢. 新型压缩空气储能系统性能研究[D]. 北京：中国科学院大学，2013. GUO Huan. Performance study on novel compressed air energy storage systems[D]. Beijing: University of Chinese Academy of Sciences, 2013. 本文引用 [1]

[6]	工程热物理研究所. “超临界压缩空气储能系统研制”通过验收][EB/OL]. http://www.cas.cn/ky/kyjz/201307/t20130724 _390463 8.shtm 本文引用 [1]

[7]	左志涛. 国际首台10 MW级压缩空气储能集成实验与验证平台开始系统联合调试[EB/OL]. http://lses.cn/dqyd/suoneidongtai/652.html 本文引用 [1]

[8]	梅生伟，薛小代，陈来军. 压缩空气储能技术及其应用探讨[J]. 南方电网技术，2016, 10(3): 11-15. MEI Shengwei, XUE Xiaodai, CHEN Laijun. Discussion on compressed air energy storage technology and its application[J]. Southern Power System Technology, 2016, 10(3): 11-15. 本文引用 [1]

[9]	裴雅晴. 500 kW压缩空气储能示范项目测控系统关键技术研究[D]. 郑州：河南工业大学，2015. PEI Yaqing. The key techniques research of measurement and control system about 500 kW of compressed air energy storage demonstration project[D]. Zhengzhou: Henan University of Technology, 2015. 本文引用 [1]

[10]	TAKAHASHI K, YASUDA T, ENDOH M, et al. Application of dynamic simulation to CAES G/T control system development[C]//ASME Turbo Expo 2002: Power for Land, Sea, and Air. 2002: 153-161. 本文引用 [1]

[11]	中华人民共和国国家经济贸易委员会. 汽轮机调节控制系统试验导则：DL/T 711—1999[S]. 北京：中国电力出版社，1999. 本文引用 [1]

[12]	许天宁，郭健，刘勇奇. 汽轮机汽门严密性试验方法探讨与实践[J]. 东北电力技术，2012, 33 (12): 47-49. XU Tianning, GUO Jian, LIU Yongchi. Discussion and practice on test method of steam door tightness of steam turbine[J]. Northeast Electric Power Technology, 2012, 33(12): 47-49. 本文引用 [1]

[13]	崔宏博，王小宁，胡劲松，等. 全、半转速核电汽轮机的比较[J]. 东方电气评论，2006, 20(2): 58-63. CUI Hongbo, WANG Xiaoning, HU Jinsong, et al. Comparison of full and half speed nuclear power steam turbine[J]. Eastern Electric review, 2006, 20(2): 58-63. 本文引用 [1]

[14]	孙小龙，宋子龙，徐建飞. 盘车转速下验证汽门严密性的试验方法[J]. 东北电力技术，2013(9): 37-40. SUN Xiaolong, SONG Zilong, XU Jianfei. Test method of valve tightness of turning speed[J]. Northeast Electric Power Technology, 2013(9): 37-40. 本文引用 [1]
