波浪能、潮流能发电场电力系统研究

段春明; 朱永强; DUAN Chunming; ZHU Yongqiang

doi:10.16513/j.cnki.10-1427/tk.2017.06.006

PDF(1690 KB)

分布式能源 ›› 2017, Vol. 2 ›› Issue (6) : 31-37. DOI: 10.16513/j.cnki.10-1427/tk.2017.06.006

波浪能、潮流能发电场电力系统研究

作者信息 +

Power System for Wave Energy and Tidal Energy Generation Site

Author information +

文章历史 +

摘要

Power system of ocean energy (wave energy and tidal energy) power generation is the core part of the whole power generation field, so the design of power system topology should be able to meet the requirements of rid connected power generation under real-time conditions, safe and reliable transportation of ocean energy power generation device. This paper firstly analyzes the structure of the power system in the power plant, compares the topologies of the energy acquisition system in several gensets from the aspects of economy and reliability, and gives two kinds of interval topologies. Based on the practical engineering experience, this paper proposes a new topological structure of energy acquisition system for generation device. At the same time, the design schemes of transmission systems of three kinds of ocean energy fields including AC system, HVDC and flexible DC are comparatively analyzed. The analysis shows that the setting of the power transmission system and the unit energy acquisition system are affected by the construction environment, the system capacity, the offshore distance, the technical mode, etc., which needs to be economically and technically comprehensively determined. The analysis results can provide technical basis for the realization of domestic ocean energy generating electric field or test site construction.

关键词

波浪能 / 潮流能 / 发电场 / 集电系统 / wave energy / tidal energy / power plant / energy acquisition system

引用本文

EndNote

Ris (Procite)

Bibtex

导出引用

段春明, 朱永强, DUAN

Chunming

, 等. Power System for Wave Energy and Tidal Energy Generation Site[J]. 分布式能源. 2017, 2(6): 31-37 https://doi.org/10.16513/j.cnki.10-1427/tk.2017.06.006

[J]. Distributed Energy Resources. 2017, 2(6): 31-37 https://doi.org/10.16513/j.cnki.10-1427/tk.2017.06.006

参考文献

列表( 原文顺序 | 文献年度倒序 | 文中引用次数倒序 ) 可视化分析

[1]	段春明. 海洋可再生能源发电场集电系统研究[D]. 北京：华北电力大学，2014. DUAN Chunming. Research on collector system of marine renewable energy farm[D]. Beijing: North China Electric Power University, 2014. 本文引用 [1]

[2]	LEWIS T. The status of ocean energy development in europe and some current research questions[C]//MTS/IEEE Kona Conference. OCEANS'11, Kona, HI, United states, September, 2011. 本文引用 [1]

[3]	申惠琪. 大型潮流能发电场的电气系统经济性分析与测试评价[D]. 北京：华北电力大学，2013. SHEN Huiqi. Economic analysis of electrical system and test about tidal current energy farm[D]. Beijing: North China Electric Power University, 2013. 本文引用 [1]

[4]	唐杨. 波浪能、潮流能试验场方案设计与并网标准研究[D]. 北京：华北电力大学，2013. TANG Yang. Wave energy, tidal current energy field test program design and grid standards[D]. Beijing: North China Electric Power University, 2013. 本文引用 [1]

[5]	王建东，李国杰. 海上风电场内部电气系统布局经济性对比[J]. 电力系统自动化，2009, 33(11): 99-103. WANG Jiandong, LI Guojie. Economic comparison of different collector networks for offshore wind farms[J]. Automation of Electric Power Systems，2009, 33(11): 99-103. 本文引用 [1]

[6]	靳静，艾芊，奚玲玲，等. 海上风电场内部电气接线系统的研究[J]. 华东电力，2007, 35(10): 20-23. JIN Jing, AI Qian, XI Lingling, et al. Internal electrical wiring systems of off-shore wind farms[J]. East China Electric Power, 2007, 35(10): 20-23. 本文引用 [1]

[7]	陈宁. 大型海上风电场集电系统优化研究[D]. 上海：上海电力学院，2011. CHEN Ning. Optimization research of large offshore wind farm collection system[D]. Shanghai: Shanghai Electric Power Institute, 2011. 本文引用 [1]

[8]	孙君洋，朱淼，高强，等. 大型海上交流风电场内部拓扑优化设计[J]. 电网技术，2013, 37(7): 1978-1982. SUN Junyang, ZHU Miao, GAO Qiang, et al. Optimal design of internal topology for high power AC offshore wind farms[J]. Power System Technology, 2013, 37(7): 1978-1982. 本文引用 [1]

[9]	段春明，朱永强，叶青，等. 海上试验场潮流能发电装置综合测试与评价方法分析[J]. 海洋通报，2014, 33(5): 566-570. DUAN Chunming, ZHU Yongqiang, YE Qing, et al. Analysis of the integrated test and evaluation methods of tidal current energy generating device in offshore testing site[J]. Marine Communications, 2014, 33(5): 566-570. 本文引用 [1]

[10]	BREUER W, CHRISTL N. 大容量陆地和海上风电场的电网接入方案[J]. 中国电力，2007, 40(3): 74-78. BREUER W, CHRISTL N. Grid access solutions for large scale on-/offshore wind park installations to the power grid[J]. Electric Power, 2007，40(3): 74-78. 本文引用 [1]
