考虑尾流效应的并网风电场等值建模与仿真

郑俊观; 王硕禾; 张立园; ZHENG Junguan; WANG Suohe; ZHANG Liyuan

doi:10.16513/j.cnki.10-1427/tk.2017.04.002

PDF(1081 KB)

分布式能源 ›› 2017, Vol. 2 ›› Issue (4) : 7-12. DOI: 10.16513/j.cnki.10-1427/tk.2017.04.002

学术研究

考虑尾流效应的并网风电场等值建模与仿真

作者信息 +

Equivalent Modeling and Simulation of Grid-Connected Wind Farm Considering Wake Effect

Author information +

文章历史 +

摘要

This paper takes grid-connected wind farm equivalent modeling as research object with considering wake effects. The wind turbine at different locations can capture the different wind speeds due to the influence of wake effects. Through Jensen model, wind direction and other factors, this paper proposes a method for the average wind speed of wind turbines. In order to save the simulation time and the influence of wake effect, wind farm is equivalent to a wind turbine and the equivalent mean wind speed is taken as input. Finally, this paper constructs the simulation model in Matlab/Simulink, and proves the correctness and validity of the model through studying wind speed disturbances and power grid fault.

关键词

并网风电场 / 双馈式风力发电机 / 尾流效应 / 等值模型 / grid-connected wind farm / doubly-fed wind generator / wake effect / equivalent model

引用本文

EndNote

Ris (Procite)

Bibtex

导出引用

郑俊观, 王硕禾, 张立园, 等. Equivalent Modeling and Simulation of Grid-Connected Wind Farm Considering Wake Effect[J]. 分布式能源. 2017, 2(4): 7-12 https://doi.org/10.16513/j.cnki.10-1427/tk.2017.04.002

[J]. Distributed Energy Resources. 2017, 2(4): 7-12 https://doi.org/10.16513/j.cnki.10-1427/tk.2017.04.002
